Image sensor | 1/2.8" Progressive Scan CMOS |
Effective pixel | 2230K pixels |
Min. illumination | Color:0.05Lux@F1.6, AGC ON; B/W:0.01Lux@F1.6, AGC ON |
White balance | Auto / Manual /ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp |
AGC | Auto / Manual |
S / N rati | o? 50dB |
Digital noise Reduction | 3D DNR |
Backlight compensation | HLC/BLC |
Wide dynamic range | Digital WDR |
Shutter speed | ~1/10,000s |
Day & Night | IR Cut Filter |
Digital zoom | 16X |
Privacy masking | 2 privacy masks programmable |
Focus mode | Auto / Semiautomatic / Manual |
Focal Length | 4.7 ~ 94mm, 20x |
Zoom Speed | Approx 3s(Optical Wide-Tele) |
Angle of View | 58.3 ~3.2 degree (Wide-Tele) |
Min. Working Distance | 10 ~1000mm(Wide-Tele) |
Aperture Range | F1.6 ~ F3.5 |
Pan / Tilt rangePan | 360° endless;Tilt:-5° ~90°(Auto Flip) |
Pan / Tilt speedPan Manual Speed | 0.1° ~250°/s, Pan Preset Speed:300°/s Tilt Manual Speed:0.1° ~250°/s, Tilt Preset Speed:200°/s |
Proportional zoom | Rotation speed can be adjusted automatically according to zoom multiples |
Number of preset | 256 |
Park action | Pattern/Pan scan/Tilt scan/Frame scan/Panorama scan/Random scan |
Patrol | 8 patrols, up to 32 presets per patrol |
Power-off memory | Support |
PTZ position display | Support |
Preset freezing | Support |
Scheduled task | Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Pan-orama scan/Dome reboot/Self-test action/Alarm output |
Audio Input | 1 Mic in/Line in interface, Line input:2 ~ 2.4V[p-p]; output impedance:1K?, ±10% |
Audio Output | 1 Audio output interface, Line level, impedance:600? |
Ethernet | 10Base-T / 100Base-TX, RJ45 connector |
Max. Image Resolution | 1920x1080 |
Frame Rate | 50Hz:25 fps (1920x1080), 25 fps (1280x960) , 25 fps (1280x720) 60Hz:30 fps (1920x1080), 30 fps (1280x960) , 30 fps (1280x720) |
Image Compression | H.264/MJPEG |
Audio Compression | G.711u /G.711a /G.726 /MP2L2 |
Protocols | IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, R T S P, R T P, T C P, U D P, IG M P, IC M P, D H C P, P P P o E |
Simultaneous Live View | Up to 6 |
Streams | Dual streams |
Mini SD Memory Card | Micro SD slot, up to 32GB |
User/Host Level | Up to 32users, 3 Levels:Administrator, Operator, User |
Security Measures | User authentication (ID and PW), Host authentication (MAC address), IP address filtering |
Application programming | Open-ended API, support Onvif, PSIA and CGI |
Web Browser | IE 7+, Chrome 18+, Firefox 5.0+, Safari 5.02+ |
Power | 24 VAC, max. 14W |
Working Temperature | -10°C ~ 50°C, 90% or less |
Protection Level | IP66 (outdoor dome) TVS 4,000V lightning protection, surge protection and voltage transient protection IK10 (optional) |
Dimensions | 220×305mm ( ?8.66”×12.02”)(Outdoor) 183 .4×243mm( ?7.22”×9.56”) (Ceiling) 245×236mm( ?9.65”×9.29”) (In-ceiling) |
Weight (approx.) | 5Kg |
