Szünetmentes tápegység

• Power

• 1000 VA / 800 W

• Type

• On-line

• Nominal Input Voltage

• 220-240 VAC

• Nominal Output Voltage

• 208/220/230/240 VAC – user selectable

• Frequency

• 50Hz / 60 Hz - user selectable

• Outlets

• 3 x Schuko Battery Backup & Surge Protection

• Transfer Time to Battery / AC

• Typical 0 ms

  Eco mode 4 ms

• Typical Backup Time

• 25% Load - 19 min

  50% Load - 6 min

  75% Load - 2 min

  100% Load - 1 min

• Communication Ports

• HID USB, RS232, EPO, SNMP

• Battery Type

• Sealed and leak proof maintenance

• Battery Specification

• 2 x GP07122L

• Software

• Monitor & Control over USB, LAN and Internet (SNMP card optional)

• Features

• Online (double conversion)

  Pure sine wave output

  Selectable output voltage by user

  Selectable output frequency by user

  Wide Input Range (80V-300V)

  Up to 96% Efficiency Rates

  Software management

  HID USB, RS2322, SNMP port communication

  Generator Compatible

  Auto-restart

  Auto-charge

  Low noise level

• Efficiency

• High efficiency up to 96%

• LCD Display

• UPS status, Load level, Battery level, Input/Output voltage, Discharge timer, and Fault conditions

• Environment

• Humidity: 0-90 % (non-condensing)

  Temperature: 0-40 grades Celsius

  Noise level: less than 40 dB

• Physical Dimensions

• Dimensions: 327 x 140 x 190 mm

  Weight: 9.13 kg

• Power

• 2000 VA / 1600 W

• Type

• On-line

• Nominal Input Voltage

• 220-240 VAC

• Nominal Output Voltage

• 208/220/230/240 VAC – user selectable

• Frequency

• 50Hz / 60 Hz - user selectable

• Outlets

• 4 x Schuko Battery Backup & Surge Protection

• Transfer Time to Battery / AC

• Typical 0 ms

  Eco mode 4 ms

• Typical Backup Time

• 25% Load - 17 min

  50% Load - 7 min

  75% Load - 3 min

  100% Load - 1 min

• Communication Ports

• HID USB, RS232, EPO, SNMP

• Battery Type

• Sealed and leak proof maintenance

• Battery Specification

• 4 x GP07122L

• Software

• Monitor & Control over USB, LAN and Internet (SNMP card optional)

• Features

• Online (double conversion)

  Pure sine wave output

  Selectable output voltage by user

  Selectable output frequency by user

  Wide Input Range (80V-300V)

  Up to 96% Efficiency Rates

  Software management

  HID USB, RS2322, SNMP port communication

  Generator Compatible

  Auto-restart

  Auto-charge

  Low noise level

• LCD Display

• UPS status, Load level, Battery level, Input/Output voltage, Discharge timer, and Fault conditions

• Environment

• Humidity: 0-90 % (non-condensing)

  Temperature: 0-40 grades Celsius

  Noise level: less than 40 dB

• Physical Dimensions

• Dimensions: 390 x 151 x 225 mm

  Weight: 16.6 kg

• Power

• 3000 VA / 2400 W

• Type

• On-line

• Nominal Input Voltage

• 220-240 VAC

• Nominal Output Voltage

• 208/220/230/240 VAC – user selectable

• Frequency

• 50Hz / 60 Hz - user selectable

• Outlets

• 4 x Schuko and Hard Wiring

• Transfer Time to Battery / AC

• Typical 0 ms

  Eco mode 4 ms

• Typical Backup Time

• 25% Load - 18 min

  50% Load - 7 min

  75% Load - 2 min

  100% Load - 1 min

• Communication Ports

• HID USB, RS232, EPO, SNMP

• Battery Type

• Sealed and leak proof maintenance

• Battery Specification

• 6 x GP07122L

• Software

• Monitor & Control over USB, LAN and Internet (SNMP card optional)

• Features

• Online (double conversion)

  Pure sine wave output

  Selectable output voltage by user

  Selectable output frequency by user

  Wide Input Range (80V-300V)

  Up to 96% Efficiency Rates

  Software management

  HID USB, RS2322. SNMP port communication

  Generator Compatible

  Auto-restart

  Auto-charge

  Low noise level

• LCD Display

• Load level, Battery level, AC mode, Battery mode, Bypass mode, Fault indicators

• Environment

• Humidity: 0-90 % (non-condensing)

  Temperature: 0-40 grades Celsius

  Noise level: less than 40 dB

• Physical Dimensions

• Dimensions: 416 x 196 x 342 mm

  Weight: 25.1 kg

EAN: 6422956011093

Típus: VRLA AGM

Volt: 12V

Tervezett élettartam: Max.: 5 év

Csatlakozó Típusa: T2

Tulajdonságok: Teljesen zárt, gondozásmentes

Alkalmazhatóság: Riasztó és biztonsági rendszerek, kábel TV, kommunikációs eszközök, nehéz szerszámok, irányító berendezés, orvosi eszközök, szünetmentes tápegységek, játékok

Méret: 90 x 70 x 101 mm

Súly: 1,41 kg

EAN: 6422956010089

Típus: VRLA AGM

Volt: 12V

Tervezett élettartam: Max.: 5 év

Csatlakozó Típusa: F2/T2

Tulajdonságok: Teljesen zárt, gondozásmentes

Alkalmazhatóság: Riasztó és biztonsági rendszerek, kábel TV, kommunikációs eszközök, nehéz szerszámok, irányító berendezés, orvosi eszközök, szünetmentes tápegységek, játékok

Méret: 151 x 65 x 95 mm

Súly: 1,98 kg

EAN: 6422956010096

Típus: VRLA AGM

Volt: 12V

Tervezett élettartam: Max.: 5 év

Csatlakozó Típusa: F2/T2

Tulajdonságok: Teljesen zárt, gondozásmentes

Alkalmazhatóság: Riasztó és biztonsági rendszerek, kábel TV, kommunikációs eszközök, nehéz szerszámok, irányító berendezés, orvosi eszközök, szünetmentes tápegységek, játékok

Méret: 151 x 65 x 95 mm

Súly: 2,48 kg

EAN: 6422956010102

Típus: VRLA AGM

Volt: 12V

Tervezett élettartam: Max.: 5 év

Csatlakozó Típusa: F2/T2

Tulajdonságok: Teljesen zárt, gondozásmentes

Alkalmazhatóság: Riasztó és biztonsági rendszerek, kábel TV, kommunikációs eszközök, nehéz szerszámok, irányító berendezés, orvosi eszközök, szünetmentes tápegységek, játékok

Méret: 151 x 98 x 95 mm

Súly: 3,3 kg

EAN: 6422956010355

Típus: VRLA AGM

Volt: 12V

Tervezett élettartam: Max.: 8 év

Csatlakozó Típusa: F2/T2

Tulajdonságok: Teljesen zárt, gondozásmentes

Alkalmazhatóság: Riasztó és biztonsági rendszerek, kábel TV, kommunikációs eszközök, nehéz szerszámok, irányító berendezés, orvosi eszközök, szünetmentes tápegységek, játékok

Méret: 151 x 65 x 95 mm

Súly: 2,5 kg

Power
1000 VA / 600 W

Nominal Input Voltage
230Vac

Accepted Input Voltage Range
162-290 VAC

Accepted Output Voltage Range
162-290 VAC

Frequency
60 Hz or 50 Hz ±1 Hz

Type
Line Interactive

Outlets
4 x Schuko

RJ11 phone line/modem surge protection

Battery Backup & Surge Protection

Transfer time
2-6 ms

Transfer Time to Battery / AC
2-6 ms

Communication Port
USB

Battery Type
Sealed and leak proof maintenance

Battery Specification
12V / 7AH x 2

Software
Software management included

Monitor & Control over USB, LAN and Internet

Operation Temperature
0 ~ 40 C

Features
Touch screen LCD to display UPS information circularly

Excellent microprocessor control guarantees high reliability

Boost and buck AVR for voltage stabilization

Auto restart while AC is recovering

Simulated sine wave

Off-mode charging

Cold start function

Software Management (ViewPower

LCD Display
Input voltage

Output Voltage

Battery capacity

Load level

UPS status

Physical Dimensions
320 x 130 x 182 mm

Power
1500 VA / 900 W

Nominal Input Voltage
230 Vac

Accepted Input Voltage Range
162-290 VAC

Accepted Output Voltage Range
196-255Vac

Frequency
50 / 60 Hz Auto detection

Outlets
4x Schuko Battery Backup & Surge Protection RJ11 phone line/modem surge protection

RJ45 surge protection

Type
Line Interactive

Transfer time
2-6 ms

Communication Port
USB

Battery Type
Sealed and leak proof maintenance

Battery Specification
12 V / 9Ah x 2

Software
Software management included

Monitor & Control over USB, LAN and Internet

Operation Temperature
0 ~ 40 C

Features
Touch screen LCD to display UPS information circularly

Excellent microprocessor control guarantees high reliability

Boost and buck AVR for voltage stabilization

Auto restart while AC is recovering

Simulated sine wave

Off-mode charging

Cold start function

Software Management (ViewPower

LCD Display
Input voltage

Output Voltage

Battery capacity

Load level

UPS status

Physical Dimensions
320 x 130 x 182 mm

Power
2000 VA / 1200 W

Nominal Input Voltage
230Vac

Accepted Input Voltage Range
162-290 VAC

Accepted Output Voltage Range
196-255Vac

Frequency
60/50 Hz (auto sensing)

Outlets
4x Schuko Battery Backup & Surge Protection

RJ11 phone line/modem surge protection

RJ45 surge protection

Type
Line Interactive

Communication Port
USB

Battery Type
Sealed and leak proof maintenance

Battery Specification
12 V / 9Ah x 2

Software
Software management included

Monitor & Control over USB, LAN and Internet

Operation Temperature
0 ~ 40 C

Features
Touch screen LCD to display UPS information circularly

Excellent microprocessor control guarantees high reliability

Boost and buck AVR for voltage stabilization

Auto restart while AC is recovering

Simulated sine wave

Off-mode charging

Cold start function

Software Management (ViewPower

LCD Display
Input voltage

Output Voltage

Battery capacity

Load level

UPS status

Transfer time
2-6 ms

Physical Dimensions
320 x 130 x 182 mm

Power
600VA / 360W

Nominal Input Voltage
230Vac

Accepted Input Voltage Range
162-290 VAC

Accepted Output Voltage Range
196-255Vac

Frequency
50 / 60 Hz Auto detection

Outlets
2x Schuko

RJ11 phone line/modem surge protection

Battery Backup & Surge Protection

Type
Line Interactive

Communication Port
USB

Transfer time
2-6 ms

Battery Type
Sealed and leak proof maintenance

Battery Specification
12V / 7AH x 1

Software
Software management included

Monitor & Control over USB, LAN and Internet

Operation Temperature
0 ~ 40 C

Features
Touch screen LCD to display UPS information circularly

Excellent microprocessor control guarantees high reliability

Boost and buck AVR for voltage stabilization

Auto restart while AC is recovering

Simulated sine wave

Off-mode charging

Cold start function

Software Management (ViewPower

Outlet Protection RJ11
1 in / 1 out

LCD Display
Input voltage

Output Voltage

Battery capacity

Load level

UPS status

Efficiency
Up to 90% Efficency Rates

Physical Dimensions
300 x 101 x 142 mm

Power
800 VA / 480 W

Nominal Input Voltage
230Vac

Accepted Input Voltage Range
160-280 VAC

Accepted Output Voltage Range
196-255Vac

Frequency
60 Hz or 50 Hz ±1 Hz

Type
Line Interactive

Outlets
2x Schuko

RJ11 phone line/modem surge protection

Battery Backup & Surge Protection

Transfer Time to Battery / AC
2-6 ms

Communication Port
USB

Battery Type
Sealed and leak proof maintenance

Battery Specification
12V 9Ah x 1

Software
Software management included

Monitor & Control over USB, LAN and Internet

Operation Temperature
0 ~ 40 C

Features
Touch screen LCD to display UPS information circularly

Excellent microprocessor control guarantees high reliability

Boost and buck AVR for voltage stabilization

Auto restart while AC is recovering

Simulated sine wave

Off-mode charging

Cold start function

Software Management (ViewPower

LCD Display
Input voltage

Output Voltage

Battery capacity

Load level

UPS status

Transfer time
2-6 ms

Physical Dimensions
300 x 101 x 142 mm

EAN: 6422956013295

Típus: VRLA AGM

Volt: 12V

Tervezett élettartam: Max.: 8 év

Csatlakozó Típusa: F2/T2

Tulajdonságok: Teljesen zárt, gondozásmentes

Alkalmazhatóság: Riasztó és biztonsági rendszerek, kábel TV, kommunikációs eszközök, nehéz szerszámok, irányító berendezés, orvosi eszközök, szünetmentes tápegységek, játékok

Méret: 151 x 65 x 94 mm

Súly: 2,68 kg

• Power

• 1000 VA / 600 W

• Type

• Line Interactive

• Nominal Input Voltage

• 230 Vac

• Nominal Output Voltage

• 230 Vac

• Accepted Input Voltage Range

• 162 ~ 290 VAC

• Frequency

• 50Hz ~ 60Hz (Auto Sensing)

• Outlets

• 4 x Schuko Battery Backup & Surge Protection

• Transfer Time to Battery / AC

• Typical 4 ms

• Typical Backup Time

• 25% Load - 22 min

  50% Load - 10 min

  75% Load - 4 min

  100% Load - 1 min

• Communication Port

• USB port / LAN (HID USB optional)

• Battery Type

• Sealed and leak proof maintenance

• Battery Specification

• 2 x GP07122L

• Software

• Monitor and control over USB

  https://www.power-softwaredownload. com/viewpower.html

• Features

• Automatic Voltage Regulation

  Overload and over voltage protection

  Lightning and Surge Protection

  Auto restart while AC is recovering

  Off mode charging

  Built-in super smart charger - 90% fully charged in 4 hours

  Smart control of power consumption saving 50% energy

• RJ45/RJ11 Protection

• 1 in / 1 out

• Environment

• Humidity: 0-90 % (non-condensing)

  Temperature: 0-40 grades Celsius

  Noise level: less than 40 dB

• Physical Dimensions

• Dimensions: 298 x 148 x 178 mm

  Weight: 7.7 kg

• Power

• 1500 VA / 900 W

• Type

• Line Interactive

• Nominal Input Voltage

• 230 Vac

• Nominal Output Voltage

• 230 Vac

• Accepted Input Voltage Range

• 162 ~ 290 VAC

• Frequency

• 50Hz ~ 60Hz (Auto Sensing)

• Outlets

• 4 Outlets with Battery Backup & Surge Protection

• Transfer Time to Battery / AC

• Typical 4 ms

• Typical Backup Time

• 25% Load - 22 min

  50% Load - 8 min

  75% Load - 2 min

  100% Load - <1 min

• Communication Port

• USB port / LAN (HID USB optional)

• Battery Type

• Sealed and leak proof maintenance

• Battery Specification

• 2 x GP09122L

• Software

• Monitor and control over USB

  https://www.power-softwaredownload. com/viewpower.html

• Features

• Automatic Voltage Regulation

  Overload and over voltage protection

  Lightning and Surge Protection

  Auto restart while AC is recovering

  Off mode charging

  Built-in super smart charger - 90% fully charged in 4 hours

• RJ45/RJ11 Protection

• 1 in / 1 out

• Environment

• Humidity: 0-90 % (non-condensing)

  Temperature: 0-40 grades Celsius

  Noise level: less than 40 dB

• Physical Dimensions

• Dimensions: 298 x 148 x 178 mm

  Weight: 9.2 kg

• Power

• 2000 VA / 1200 W

• Type

• Line Interactive

• Nominal Input Voltage

• 230 Vac

• Nominal Output Voltage

• 230 Vac

• Accepted Input Voltage Range

• 162 ~ 290 VAC

• Frequency

• 50Hz ~ 60Hz (Auto Sensing)

• Outlets

• 4 Outlets with Battery Backup & Surge Protection

• Transfer Time to Battery / AC

• Typical 4 ms

• Typical Backup Time

• 25% Load - 13 min

  50% Load - 4 min

  75% Load - 1 min

  100% Load - <1 min

• Communication Port

• USB port / LAN (HID USB optional)

• Battery Type

• Sealed and leak proof maintenance

• Battery Specification

• 2 x GP09122L

• Software

• Monitor and control over USB

  https://www.power-softwaredownload. com/viewpower.html

• RJ45/RJ11 Protection

• 1 in / 1 out

• Environment

• Humidity: 0-90 % (non-condensing)

  Temperature: 0-40 grades Celsius

  Noise level: less than 40 dB

• Physical Dimensions

• Dimensions: 298 x 148 x 178 mm

  Weight: 10.6 kg
